Satellite communication has allowed for advances in global navigation, weather, mobile phones, radio, and television.
The Up-Link and Down-Link segments of Satellite’s contain RF frequencies up to approximately 7 GHz (L, S, and C-Bands) and for the 5G mobile/base station configurations up to 6 GHz and in the milli-meter wave bands (24 to 86 GHz).
On the receive side a weak analog signal is amplified and down converted to an Intermediate Frequency (IF) which is then fed into a high-performance digitizer for efficient processing.
What to consider when selecting a digitizer for Satellite Communication applications
Wide analog bandwidth for flexibility in selecting the IF bandwidth
High speed sampling needed for signal bandwidth and low noise aliasing
High spurious free dynamic range to resolve low level signals
Digital down converter to reduce the sample frequency and increase signal to noise ratio
Decimation filtering for improved ENOB
Open FPGA for custom real-time digital signal processing
High data transfer rate is needed to support fast post-processing
Global Navigation Satellite System (GNSS) use L-band up to 1.6 GHz. This can be recorded by direct sampling and avoiding analog mixers.
Further Reading / Next Steps
For information about the FW2DDC firmware package (Digital Down-conversion Firmware) and the frequency planning see here.
For information about the optional firmware packages and development kit see here.
